Hoses

for pneumatics and water applications

RTC Hose up to 90°C
Type PLOK-G
Push to Connect
Inner diameter 9,5 / 12,7 / 16 / 19 / 25,4 mm
Outer diameter 15,5 / 19,5 / 22,6 / 25,8 / 33,2 mm
Pressure range 0 - 28 bar
Temperature range -40°C - +90°C
Bending radius 80 - 170 mm

PDF
RTC Hose up to 120°C
Type LOCK-120S
Push to Connect
Inner diameter 10 / 13 / 16 / 19 mm
Outer diameter 16 / 20 / 24 / 27 mm
Pressure range 0 - 16 bar
Temperature range -40°C - +120°C
Bending radius 85 - 170 mm

PDF
RTC hose up to 140°C
Type HLOK-G
Push to Connect
Outer diameter 9,5 / 12,7 / 16 / 19 / 25,4 mm
Inner diameter 15,5 / 19,5 / 22,6 / 25,8 / 33,2 mm
Pressure range 0 - 28 bar
Temperature range -40°C - +140°C
Bending radius 75 - 170 mm

PDF
RTC flexible hose up to 200°C
Type RTH
Flexible hose
Inner diameter 6,8 / 7,7 / 9,7 / 12,5 / 15,5 / 19,8 / 28 mm
Outer diameter 11,5 / 12,5 / 15 / 18 / 22 / 27 / 34,8 mm
Pressure range 0 - 90 bar
Temperature range -50°C - +200°C
Bending radius 30 - 80 mm

PDF
RTC Water and Air Hose up to 95°C
Type MNG
abrasion resistant
Inner diameter 10 / 13 mm
Outer diameter 17 / 21 mm
Pressure range 0 - 20 bar
Temperature range -25°C - +95°C
Bending radius ---

PDF

All our products can be found in our current RTC catalogue
